DIP Double Sides LED Cross Display 1495*1030*70mm Screen Dimension CE Assured

    Buy cheap DIP Double Sides LED Cross Display 1495*1030*70mm Screen Dimension CE Assured from wholesalers

    Buy cheap DIP Double Sides LED Cross Display 1495*1030*70mm Screen Dimension CE Assured from wholesalers
    • Buy cheap DIP Double Sides LED Cross Display 1495*1030*70mm Screen Dimension CE Assured from wholesalers
    • Buy cheap DIP Double Sides LED Cross Display 1495*1030*70mm Screen Dimension CE Assured from wholesalers
    • Buy cheap DIP Double Sides LED Cross Display 1495*1030*70mm Screen Dimension CE Assured from wholesalers
    • Buy cheap DIP Double Sides LED Cross Display 1495*1030*70mm Screen Dimension CE Assured from wholesalers
    • Buy cheap DIP Double Sides LED Cross Display 1495*1030*70mm Screen Dimension CE Assured from wholesalers
    • Buy cheap DIP Double Sides LED Cross Display 1495*1030*70mm Screen Dimension CE Assured from wholesalers

    DIP Double Sides LED Cross Display 1495*1030*70mm Screen Dimension CE Assured

    Ask Lasest Price
    Brand Name : Singheng
    Model Number : P10
    Price : USD+To be negotiated+piece | 1 Piece/Pieces (Min. Order)
    Certification : CE RoHS UL Certifications
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 3000+square meter+per month
    Delivery Time : About 16 days
    • Product Details
    • Company Profile

    DIP Double Sides LED Cross Display 1495*1030*70mm Screen Dimension CE Assured

    Dip Double Sides Led Pharmacy Cross Display For Hospital


    • Product description

    1. The LED cross display can display various graphics and texts, has a rich playback mode,and has a large capacity for storing information

    2. Suitable for all pharmacies, hospitals, churches, etc.

    3. Fonts and font size can be arbitrarily selected, the playback speed can be set, and multiple messages can be broadcast simultaneously.

    4. The control system has multimedia software, which can make the LED cross display broadcast a variety of information

    5. Date, time and temperature can be displayed

    6. This LED cross screen can be made in monochrome and two-color. Monochrome and two-color are in-line DIP modules.

    7. Multi-language display: English, French, Italian, Spanish,Russian, etc.


    • Product description of P16 LED Cross

    Item

    Product paramenter

    Pixel Pitch

    16mm

    Pixel Density

    dot/sqm

    Pixel configuration

    2R1G

    Module Size

    256*128 mm

    LED brand

    Taiwai EPISTAR

    Cabinet type

    Constant drive

    Cabinet Material

    SPCC

    Weight

    37KG

    Viewing Distance

    5-30m

    Viewing Angle (Horizontal Axis)

    160°

    Viewing Angle (Vertical Axis)

    160°

    Refresh Rate

    >1920Hz

    Grey Scale

    65536

    Brightness

    ≥3000cd/sqm

    Max Power Consumption

    400w/sqm

    Average Power Consumption

    160w/sqm

    Drive Mode

    1/4Scant

    Signal EMC

    VGA,DIV,HDMI,SDI

    Lifespan

    ≥10,0000 h

    Waterproof Grade

    IP65

    Input Voltage

    AC105-235V 50-60HZ

    Celsius

    -20℃-+50℃, -35℃~+85℃

    humidity

    10-95%RH

    Control Distance

    Network Cable≤100m, Multimode optical fiber≤500m, Single mode optical≤20 kilometer


    • FAQ

    Q1:LED display models are generally expressed in PX, such as P2 P3 P4....P8 P10.What does this mean?
    A: P2 P3 P4.....P8 P10 means the pixel pitch is 2mm 3mm 4mm....8mm 10mm,which determines the number of pixels per unit area of a display. So it represents the clarity of the display. The smaller the pitch, the higher the clarity. Usually, the models of indoor full color display are P1.875,P2.5,P3,P4,P5. Outdoor full color display are P4,P5,P6,P8,P10.


    Q7:What about the lead time?
    A:Orders less than 50 square meters display ,lead time is 16 days.


    Q5:How about your quality?
    A:The quality of our display is excellent. We use the materials of high quality suppliers, strictly control the production process. and pass the multiple quality inspection to ensure every product is qualified.


    Q6:What about the warranty?
    A:Three year warranty


    Q10:How long is the transportation time?
    A:Shipping:20-30 days.Airlift:3-7 days


    Q3: To order a display, what information should l offer you?
    A:You should provide width and height of the display, the main usage, the viewing distance, the scene photo and special requirements, then I can provide you a quotation. Sometimes you should also provide information such as geographical location, local climate.

    • Product Picture
