P31.25 Ultrathin Transparent Led Curtain Extremely Strong Wind Load Capacity

    Buy cheap P31.25 Ultrathin Transparent Led Curtain Extremely Strong Wind Load Capacity from wholesalers

    Buy cheap P31.25 Ultrathin Transparent Led Curtain Extremely Strong Wind Load Capacity from wholesalers
    • Buy cheap P31.25 Ultrathin Transparent Led Curtain Extremely Strong Wind Load Capacity from wholesalers
    • Buy cheap P31.25 Ultrathin Transparent Led Curtain Extremely Strong Wind Load Capacity from wholesalers
    • Buy cheap P31.25 Ultrathin Transparent Led Curtain Extremely Strong Wind Load Capacity from wholesalers

    P31.25 Ultrathin Transparent Led Curtain Extremely Strong Wind Load Capacity

    Ask Lasest Price
    Brand Name : Singheng
    Model Number : P31.25
    Price : USD+To be negotiated+square meter
    Certification : CE RoHS UL Certifications
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 3000+square meter+per month
    Delivery Time : About 16 days
    • Product Details
    • Company Profile

    P31.25 Ultrathin Transparent Led Curtain Extremely Strong Wind Load Capacity

    P31.25 Ultra Light Ultra Thin Grille Screen Curtain Led Display Outdoor

    • Product description

    1. High performance and low power consumption. The real energy saving comes from: high-brightness, high-efficiency LED lights, high conversion efficiency power supplies.

    2. Highly integrated. Built-in power supply and receiving card, each unit can work independently; power and signal are plugged in one line

    3. IP67 high protection level. The concept of IP67 is soaking and waterproofing, that is, the overall immersion of the product.

    4. Easy to install and easy to maintain. It is installed without steel structure and does not require air conditioning.

    5. LED curtain screen is a kind of LED screen composed of light bars, also called LED light bar screen. Mainly used in outdoor walls, glass curtain walls, building tops and other fields.

    6. Also known as LED light bar screen, LED grid screen, LED glass curtain wall display, LED strip screen, LED shaped screen.

    7. Light weight and low wind load. The light weight is due to the screen grid, which makes the LED display transparent, so its wind load capacity is extremely strong.


    • Technical parameter of P31.25 Outdoor Curtain LED

    OUTDOOR FULL-COLOR DISPLAY TECHNICAL PARAMETER
    ItemP31.25
    Pixel Pitch31.25 mm
    Pixel Density1024dot/sqm
    Pixel Configuration1R1G1B DIP346
    LED brandTaiwai EPISTAR
    Cabinet typetransparent
    Weight18KG/sqm
    Cabinet Materialaluminum
    Viewing Distance≥32 m
    Viewing Angle (Horizontal)120°
    Viewing Angle (Vertical)60°
    Refresh Rate>1920Hz
    Grey Scale65536
    Brightness≥8000cd/m2
    Max Power Consumption290w/sqm
    Average Power Consumption110 w/sqm
    Drive ModeStatic
    Lifespan≥10,0000 h
    Waterproof GradeIP67
    Input VoltageAC105-235V 50-60HZ
    Celsius—40℃-40℃
    humidity10—85%RH

    • FAQ

    Q1:What pixel pitch should I choose on my display?
    A:Using the PX screen, it is determined mainly by the viewing distance, the size of the display screen, the
    desired effect and the customer budget. It is generally believed that P5 is suitable for watching outside 5
    meters, P10 is suitable for watching outside 10 meters, and P16 is suitable for watching outside 16 meters,
    and the other is the same. Of course, this data is not very accurate, and the customer just can refer to
    it. It also depends on the size of the screen, generally it is considered that more than 100 thousand
    pixels for a full color display then have a standard effect.


    Q2: To order a display ,What kind of information do I have to offer you?

    A:You should provide width/height of
    the display, the main use, the viewing distance, the scene photos, special requirements,then I can provide
    you with a detailed list of quotations. Sometimes you should also provide information such as display
    orientation, geographical location, local climate, and so on.


    Q3:Is it OK to print my logo on your product?

    A:Yes,We support OEM and ODM services .


    Q4:How long is the transportation time?
    A:Shipping: 20-30 days,Airlift: within 3-7 days.


    Q5:What about the warranty?

    A:Three year warranty


    Q6:What about the lead time?
    A:Orders less than 100 square meter display, lead time is 13-15 days.


    • Product Picture

    P31.25 Ultrathin Transparent Led Curtain Extremely Strong Wind Load Capacity
