    P20 Decorative Digital LED Curtain Screen Full Color Tube Chip Colors

    Ask Lasest Price
    Brand Name : Singheng
    Model Number : P20
    Price : USD+To be negotiated+square meter
    Certification : CE RoHS UL FCC
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 3000+square meter+per month
    Delivery Time : About 16 days
    • Product Details
    • Company Profile

    P20 Decorative Digital LED Curtain Screen Full Color Tube Chip Colors

    P20 Decorative Digital Grille Screen Panels Flexible LED Curtain Display


    • Product description

    1. High performance and low power consumption. The real energy saving comes from: high-brightness, high-efficiency LED lights, high conversion efficiency power supplies.

    2. Highly integrated. Built-in power supply and receiving card, each unit can work independently; power and signal are plugged in one line

    3. IP67 high protection level. The concept of IP67 is soaking and waterproofing, that is, the overall immersion of the product.

    4. Easy to install and easy to maintain. It is installed without steel structure and does not require air conditioning.

    5. LED curtain screen is a kind of LED screen composed of light bars, also called LED light bar screen. Mainly used in outdoor walls, glass curtain walls, building tops and other fields.

    6. LED grille screen breaks through the limitation of conventional LED display to the building and wall ,making the project more flexible and more selective.

    7. It is suitable for the construction of super large outdoor display, which is the first choice for creating landmark dynamic display landscape.


    • Technical parameter of P20 Outdoor Curtain LED
    Technical parameters

    Pixel Pitch

    20mm

    Pixel Density

    2500dot/sqm

    Pixel Configuration

    2R1G1B DIP346

    Module Size

    320*160 mm

    Module Resolution

    16*8dot

    Cabinet Material

    SPCC

    Viewing Distance

    ≥20 m

    Viewing Angle (Horizontal Axis)

    120°

    Viewing Angle (Vertical Axis)

    80°

    Refresh Rate

    >600Hz

    Grey Scale

    65536

    Brightness

    ≥8000cd/sqm

    Max Power Consumption

    700 w/sqm

    Average Power Consumption

    250 w/sqm

    Drive Mode

    static

    Signal EMC

    VGA,DIV,HDMI,SDI

    Signal Transmission Mode

    568B

    Network Cable

    ≤100m, Multimode

    Control Distance

    optical fiber≤500m, Single mode optical

    Lifespan

    ≥10,0000 h

    Input Voltage

    AC220V±10% 50-60HZ

    Celsius

    Degree:—10℃-40℃


    • FAQ

    Q1:LED display models are generally expressed in PX, such as P2 P3 P4....P8 P10.What does this mean?
    A: P2 P3 P4.....P8 P10 means the pixel pitch is 2mm 3mm 4mm....8mm 10mm,which determines the number of pixels per unit area of a display. So it represents the clarity of the display. The smaller the pitch, the higher the clarity. Usually, the models of indoor full color display are P1.875,P2.5,P3,P4,P5. Outdoor full color display are P4,P5,P6,P8,P10.


    Q2:How about your quality?
    A:The quality of our display is excellent. We use the materials of high quality suppliers, strictly control the production process. and pass the multiple quality inspection to ensure every product is qualified.


    Q3: To order a display, what information should l offer you?
    A:You should provide width and height of the display, the main usage, the viewing distance, the scene photo and special requirements, then I can provide you a quotation. Sometimes you should also provide information such as geographical location, local climate.


    Q4:What about the warranty?
    A:Three year warranty


    Q5:How long is the transportation time?
    A:Shipping:20-30 days.Airlift:3-7 days


    Q6:How to install?
    A:Free of charge to provide detailed steel structure drawings and installation guidance, wiring diagram and free remote debugging .We can also send our engineers to the site to guide the installation.
