    P5 Energy Saving Full Color LED Display Panel 192x192 Resolution Of Cabinet

    Ask Lasest Price
    Brand Name : Singheng
    Model Number : P5
    Certification : CE RoHS UL Certifications
    Price : USD+To be negotiated+square meter
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 3000+square meter+per month
    Delivery Time : About 16 days
    • Product Details
    • Company Profile

    P5 Energy Saving Full Color LED Display Panel 192x192 Resolution Of Cabinet

    Full Color Led Indoor P5 Led Display Panel Led Display Board Price​


    • Product Description

    1. High contrast rate up to 5000:1 by using black LED.

    2. Complete series, customized to satiny any requirements of customers

    3. The appearance of full color LED Board is very simple and elegant,looks very high end.

    4. With the high quality raw material, mature process and scale production,the quality is ensured.
    5. Indoor HD LED display leader, very mature product. Initial creator for such panel.Super slim, light weight, can meet the most demanding requirements.

    6. The cabinet is light in weight,low installation cost and low power consumption, saving operating costs and reducing labor costs.


    • Technical Prameters​ of P5 Led Display Panel

    Pixel pitch5mm
    Pixel Configuration1R1G1B
    LED componentSMD3528
    Size of module320mm x 160mm
    Resolution of module64x32
    Size of cabinet960mm x 960mm x 110mm
    Resolution of cabinet192x192
    Material of CabinetIron
    Weight of Cabinet8KG
    Brightness>1200cd/sqm
    Density160000dots/sqm
    Best viewing angle140 /120
    Best viewing distance5-30M
    Maximum power consumption440W/sqm
    Average power consumption190W/sqm
    Driving method1/16scan
    Control methodSynchronization
    Gray scale65536
    Color temperature3200-9300k
    Uniformity97%
    Working voltageAC220V/110V±10%
    Working temperature-20ºC~+50ºC±10%
    Working humidity10% ~ 90%
    MTBF10,000 hours
    Frame frequence50/60Hz
    Refresh frequence>1920Hz
    IP gradeIP30
    Life Span100,000 hours
    Data transafer methodRJ45
    Pratical standardCCC TUV-CE ETL etc.
    Effectivce Communication
    Distance(without relay)
    Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
    Single-mode optic fiber: 10KM
    Accepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.
    Systems operating platformWINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development

    • FAQ

    Q1: To order a display, what information should l offer you?
    A:You should provide width and height of the display, the main usage, the viewing distance, the scene photo and special requirements, then I can provide you a quotation. Sometimes you should also provide information such as geographical location, local climate.


    Q2:LED display models are generally expressed in PX, such as P2 P3 P4....P8 P10.What does this mean?
    A: P2 P3 P4.....P8 P10 means the pixel pitch is 2mm 3mm 4mm....8mm 10mm,which determines the number of pixels per unit area of a display. So it represents the clarity of the display. The smaller the pitch, the higher the clarity. Usually, the models of indoor full color display are P1.875,P2.5,P3,P4,P5. Outdoor full color display are P4,P5,P6,P8,P10.


    Q3:Is it OK to print my LOGO on your product?
    A:Yes.We support OEM and ODM service.


    Q4:What about the warranty?
    A:Three year warranty


    Q5:How about your quality?
    A:The quality of our display is excellent. We use the materials of high quality suppliers, strictly control the production process. and pass the multiple quality inspection to ensure every product is qualified.
